15 inch Industrial Grade Panel PC with Windows OS.
.jpg)
|
15 inch Industrial Grade Panel PC with Windows OS. |
||
|
Size |
15 inch; XS150-W210-4125 |
15.6 inch; XS156-W210-4125 |
|
Display |
||
|
Panel Type |
Industrial A grade LCD with LED backlight |
|
|
Aspect Ratio |
4:3 |
16:9 |
|
Resolution |
1024*768 |
1920*1080 |
|
Contrast |
800:1 |
800:1 |
|
Luminance |
300nit, up to 1500 nits |
300nit, up to 1000 nits |
|
Response time |
5ms |
5ms |
|
Active Area (mm) |
304.1*228.1 |
344.2*193.6 |
|
Display colors |
16.7M(8-bit) |
16.7M(8-bit) |
|
PC Configuration |
|
|
|
CPU |
Intel® Celeron® Processor J4125, 4M Cache, up to 2.70 GHz; |
|
|
Graphic Card |
Integrated Intel HD Graphics |
|
|
Inner memory |
4GB DDR4 1333 MHz RAM ( 8GB RAM can be customized) |
|
|
Storage |
256GB SSD (64GB/128GB/256GB/512GB SSD, 500GG/1TB HDD can be customized) |
|
|
Expansion Card Slot |
2xMini-PCIE slot, support SSD, WIFI, 3G module |
|
|
Audio |
Realtek ALG662 6 sound track audio frequency |
|
|
Internet |
1xRTL811E gigabit network card |
|
|
Operating System |
Windows 7/8.1/10, WES7-E/P, WE8S, Ubuntu 14.04 |
|
|
Support multi-language |
English/Portuguese/French…etc |
|
|
Touch Screen |
Default with 10-point capacitive touch, support Two-finger Touch Control while Wearing Gloves; |
|
|
Touch Screen Surface Hardness |
7 Mohs |
|
|
Touch Screen Transparency |
90% (±3%) |
|
|
I/O Ports |
1*12V DC input (ATX is optional) , |
|
|
2*RJ-45 network interface, |
||
|
Power Input |
AC 110-240V, 50/60Hz |
|
|
Power Consumption (Typical) |
1.53A @ 12V (18.4W) |
|
|
Power Consumption (Max) |
1.8A @ 12V (21.6W) |
|
|
Operation Temperature |
-10°C-60°C |
|
|
Storage Temperature |
-40°C-85°C |
|
|
Operation Humidity |
5%--80% |
|
|
Storage Humidity |
5%-90% |
|
|
Material |
Aluminum alloy enclosure |
|
|
Bezel Thickness |
3mm bezel |
|
|
IP Rating |
IP65 True Flat Front Panel |
|
|
Color |
Default with Black Color; Optional Silver Color; |
|
|
Installation Way |
Default with Embedded / Wall Mount bracket; VESA / Desktop optional |
|
|
Certification |
CE,FCC,ROHS,ISO9001 |
|
|
Warranty |
2 years warranty (with the exception of man-made damage) |
|
|
Packaging |
EPE+Carton (wooden crate for mass order) |
|
|
Dimensions (L x W x H) |
15inch with 379 x 300 x 63.1 mm (14.92" x 11.81" x 2.49"); |
|
|
Packing List |
1 x XS156-W210(XS156-W210); |
|
|
Applications |
Human Machine Interface (HMI); |
|
