Industrial Computer Fanless Industrial PC Intel Core For Harsh Environment

Jawest Industrial Computer Datasheet

CPU Intel Bay trail J1800 / J1900 processor, fanless
EMMC 32G SSD by default (SSD: 64G-512G; HDD mechanical hard disk 500G-1T optional)
Inner Memory 2G DDR3 (8G DDR3 optional)
Display Chip Mali400MP2 dual-core
Operating System Win7/8/10; Linux
Graphics Card Intel HD Graphics
HD support 1080P
WIFI Dual-frequency 2.4/5G
Bluetooth and GPS / MIC / RTC / Wake on LAN / Speaker / Plug-and-play Yes
USB interface USB2.0*5+USB3.0*1

200mm (L) x 189mm (W) x 59mm (H)




Aluminum Alloy Material

Serial ports

Two-channel 232 serial ports, 422/485 optional

Operating Temperature

-20 ~ +65°C ( wide temperature operation is customizable )

Storage Temperature -40 ~ +80°C
Environmental Humidity

< 80% ( full waterproof is customizable)


Black (customizable)


COM*6, Network port*1, audio output*1, VGA*1, HDMI *1, WiFi interface*1, DC power interface*1, RJ45*1 Special interface can be customized.

Installation method Embedded mount

Power supply

100-240V, 50-60 Hz

Power Consumption
